EW-D ASA CH38 Antenna Splitter for EW-D/EW100/EW300/EW500

« return to previous page

Sennheiser EW-D ASA CH38 Antenna Splitter for EW-D/EW100/EW300/EW500 - Main Image

Sennheiser EW-D ASA CH38 Antenna Splitter for EW-D/EW100/EW300/EW500 - Image 1

Sennheiser EW-D ASA CH38 Antenna Splitter for EW-D/EW100/EW300/EW500 - Image 2

Sennheiser EW-D ASA CH38 Antenna Splitter for EW-D/EW100/EW300/EW500 - Image 3

Sennheiser EW-D ASA CH38 Antenna Splitter for EW-D/EW100/EW300/EW500 - Image 4

Price:: RRP: £718.80 inc VAT
Code:: SENEWDASA38
Manufacturer Code:: 508879
Brand:: Sennheiser

Main Features

REPLACEMENT FOR ASA214 ANTENNA SPLITTER
Compatible with EW-D and G3/G4 EW100, EW300 & EW500 (CH38) Systems
Digital transmission operating in the UHF spectrum greatly enhances range, reliability and scalability
Smart Assist App connects via Bluetooth Low Energy for a streamlined setup and operation at a distance
Auto-scan creates reliable connections with minimal time and effort
134 dB audio input dynamic range eliminates the need for sensitivity adjustments and preserves every detail

Evolution Wireless Digital ASA Active Antenna Splitter with 8 BNC Cables (Q-R-S) CH38

Active Antenna Splitter for use with Evolution Wireless Digital systems.

Versatile and feature-rich digital wireless system for those who sing, speak or play instruments that allows for seamless product pairing and management via the EW-D Smart Assist App. Receive state-of-the-art live sound.

The EW-D ASA does not supply power to EW-DX.

Product Features

Digital transmission operating in the UHF spectrum greatly enhances range, reliability and scalability
Smart Assist App connects via Bluetooth Low Energy for a streamlined setup and operation at a distance
Auto scan creates reliable connections with minimal time and effort
134 dB audio input dynamic range eliminates need for sensitivity adjustments and preserves every detail
Elimination of intermodulation enables channels to be placed in an equidistant tuning grid 600 kHz apart
56 MHz of tuning bandwidth and equidistant spacing enables up to 90 channels
2,240 selectable frequencies allow for fine tuning
Lithium-Ion battery pack (sold separately) delivers up to 12 hours of operation (up to 8 hours of operation with 2x provided AA batteries)

Product Specifications

Frequency ranges
- EW-D ASA (Q-R-S): 470 – 694 MHz
- EW-D ASA CN/ANZ (Q-R-S): 470 – 694 MHz
- EW-D ASA (T-U-V-W): 694 – 1075 MHz
- EW-D ASA (X-Y): 1350 – 1805 MHz
Antenna splitter: 2 x 1:4 or 1 x 1:8, active
Gain
- in A – out A: 0 ± 1 dB
- in A – out A1 ... A4: 0 ± 1 dB
- in B – out B1 ... B4: 0 ± 1 dB
IIP3: > 25 dBm
Impedance: 50 Ω
Reflection loss: 10 dB (all RF outputs)
Operating voltage: DC +12 V from NT 12-35 CS power supply unit
Current consumption: 210 mA
Total current consumption: max. 3 A (with 4 EW-D EM and connected EW-D AB)
Supply for antenna boosters at ANT RF in A and ANT RF in B: DC 12 V; 320 mA
Supply for receivers at A1 to A4
- DC 12 V
- Typically 350 mA, max. 500 mA
Dimensions: Approx. 212 x 168 x 43 mm
Weight: Approx. 1100 g
Operating temperature range: -10 °C - +55 °C (14 °F - 131 °F)
Storage temperature range: -20 °C - +70 °C (-4 °F - 158 °F)
Relative humidity: 5 - 95 % (non-condensing)
