NX 915-A 15

« return to previous page

RCF NX 915-A 15 2-Way Active Loudspeaker System 2100W Peak Black - Image 1

RCF NX 915-A 15 2-Way Active Loudspeaker System 2100W Peak Black - Image 2

RCF NX 915-A 15 2-Way Active Loudspeaker System 2100W Peak Black - Image 3

RCF NX 915-A 15 2-Way Active Loudspeaker System 2100W Peak Black - Image 4

RCF NX 915-A 15 2-Way Active Loudspeaker System 2100W Peak Black - Image 5

RCF NX 915-A 15 2-Way Active Loudspeaker System 2100W Peak Black - Image 6

RCF NX 915-A 15 2-Way Active Loudspeaker System 2100W Peak Black - Image 7

Price:: RRP: £1,117.20 inc VAT
Code:: RCFNX915A
Manufacturer Code:: 13000674
Brand:: RCF

Main Features

2100W Class-D Bi-Amplification
45-20000 Hz linear frequency response
1.75" Compression Driver
15" Woofer
FiRPHASE zero degrees phase technology
Bass Motion Control woofer excursion management

NX 915-A 15 2-Way Active Loudspeaker System 2100W Peak Black

NX 915-A is masterfully engineered from the ground up to deliver stellar audio performance for solo musicians, bands, and DJs. The combination of 1.75" compression driver, 15" woofer, two-channel 2100W amplifier, and a constant directivity waveguide produces coherent 100° x 60° coverage for the listening area with up to 131 dB SPL, distortion-free sound. Used stand-alone speaker for FOH system, satellite (with subwoofer), stage monitor, or flown speaker, the NX 915-A blends high-performance and reliability in a compact package. Built specifically for demanding live sound applications, it also features multiple rigging points for fixed installation. Blending RCF proprietary FiRPHASE and Bass Motion Control DSP processing, NX 9 Series speakers are perfectly tuned for each model, delivering absolute clarity and deep, powerful bass response. The tour-ready, rugged all-wood cabinet is easy to carry and secure to install on a pole-, flown-, wall-, or truss-mounted using the dedicated rigging points available.

Product Features

Up to 131 dB Sound Pressure Level
2100W Class-D Bi-Amplification
45-20000 Hz linear frequency response
1.75" Compression Driver
15" Woofer
FiRPHASE zero degrees phase technology
Bass Motion Control woofer excursion management

Product Specifications

Acoustical specifications

Frequency Response: 45 Hz ÷ 20000 Hz
Max SPL @ 1m: 131 dB
Horizontal coverage angle: 100°
Vertical coverage angle: 60°

Transducers

Compression Driver: 1 x 1.0'', 1.75'' v.c
Woofer: 15'', 2.5'' v.c

Input/Output section

Input signal: bal/unbal
Input connectors: XLR, Jack
Output connectors: XLR
Input sensitivity: -2 dBu/+4 dBu

Processor section

Crossover Frequencies: 1600 Hz
Protections: Thermal, RMS
Limiter: Soft Limiter
Controls: Linear, Boost, Stage, Volume

Power section

Total Power: 2100 W Peak
High frequencies: 700 W Peak
Low frequencies: 1400 W Peak
Cooling: Convection
Connections: VDE

Standard compliance

CE marking: Yes

Physical specifications

Cabinet/Case Material: Plywood
Hardware: 2 x M10 Top, 1 x M10 each side, 1 x M10
bottom, 1 x M10 rear
Handles: 1 x Each Side
Pole mount/Cap: Yes
Grille: Steel
Color: Black

Size

Height: 705 mm / 27.76 inches
Width: 420 mm / 16.54 inches
Depth: 451 mm / 17.76 inches
Weight: 24.1 kg / 53.13 lbs

Shipping information

Package Height: 751 mm / 29.57 inches
Package Width: 506 mm / 19.92 inches
Package Depth: 474 mm / 18.66 inches
Package Weight: 26.6 kg / 58.64 lbs

Optional Accessories

AC PMA Speaker Pole Mount
AC PMX Speaker Pole Mount
AC PRO-FS Professional Loudspeaker Floor Stand
AC PRO-LF Professional Adapter Sleeve
AC PRO-PM Pole Mount with Ring Lock
PM-KIT M20 M20 Pole Mount
CVR NX 915 Protection Cover
