The BLU-3 wall panel is a simple controller which allows the designer to provide level control and source selection or preset recall in a simple wall-mounted panel.
The controller connects to the control ports on the rear of any BLU-16, BLU-32 or BLU-80 device.
The BLU-3 offers a rotary fader and a five-way switch. The switch could select system presets (configurations specific to times of the day for example) while the rotary control could be assigned to act as a zone volume control.
The switches have blank areas for marking the switch functions, either directly onto the white area, or on self-adhesive labels.
- Screw Terminals x 3: GND connection (to Control Ports COMMON pin). SOURCE / PRESET SELECT connection. LEVEL connection
- Color: Blues
- Dimensions: (H x W) 3.35" x 3.35" (85mm x 85mm)
