CS-S3B 3" 2-Way Wall Speaker With U Bracket 100V/16Ω Black

« return to previous page
Cloud CS-S3B 3 2-Way Wall Speaker With U Bracket 100V/16Ω Black - Main Image
Cloud CS-S3B 3 2-Way Wall Speaker With U Bracket 100V/16Ω Black - Image 1
Cloud CS-S3B 3 2-Way Wall Speaker With U Bracket 100V/16Ω Black - Image 2
Cloud CS-S3B 3 2-Way Wall Speaker With U Bracket 100V/16Ω Black - Image 3
Cloud CS-S3B 3 2-Way Wall Speaker With U Bracket 100V/16Ω Black - Image 4
Cloud CS-S3B 3 2-Way Wall Speaker With U Bracket 100V/16Ω Black - Image 5
Cloud CS-S3B 3 2-Way Wall Speaker With U Bracket 100V/16Ω Black - Image 6
Cloud CS-S3B 3 2-Way Wall Speaker With U Bracket 100V/16Ω Black - Image 7
Cloud CS-S3B 3 2-Way Wall Speaker With U Bracket 100V/16Ω Black - Image 8
Price:
RRP: £102.00 inc VAT
Code:
CLOCSS3B
Manufacturer Code:
CS-S3B
Brand:
Cloud

Quantity required:

Main Features

  • 3" Polypropylene Woofer with Rubber Surround with Phase Plug
  • 2-way drivers offering consistent dispersion across broad frequency ranges
  • Omidirectional mounting system
  • Removable logos to allow for discrete use
  • Deep backcan design
  • Magnetic speaker grilles available in black or white
Share:

CSS3B  Black 3" 2-Way Omnimount Speaker 100V/16ohm

Cloud's new CS-S3 is a 3" full range surface mount speaker, offers the industry’s most innovative omnidirectional mounting system. The CS-S3 offer consistent dispersion across broad frequency ranges, available in Black or White and removable logos ensure Cloud speakers can be used discretely or prominently in almost any venue. All models are sonically matched with the C series for uniform acoustics. The CS-SUB8 compliments any model to add deep, impactful bass.

Custom built for quality performance Cloud speakers are designed and tested to a superior standard by engineers who care and include a comprehensive 5-year commercial warranty.

Product Features

  • 3" Polypropylene Woofer with Rubber Surround with Phase Plug
  • 2-way drivers offering consistent dispersion across broad frequency ranges
  • Omidirectional mounting system
  • Removable logos to allow for discrete use
  • Deep backcan design
  • Magnetic speaker grilles available in black or white
  • Accessible high-impedance or low impedance switch settings

Product Specifications

General

  • Response (f3): 86 Hz -20 kHz
  • Response (f10): 64 Hz -20 kHz
  • Impedance: 16 ohm
  • Sensitivity (2.83 V/1 m): 89 dB
  • Sensitivity (1 W/1 m): 92 dB
  • Power handling: 75 W
  • Maximum SPL: 111 dB
  • Average coverage angle (2 kHz - 10 kHz): 107°
  • Transformer taps: 100v - 16W, 8W, 4W, 2W or 16W@16Ω.
  • Tweeter: 1 inch silk dome with phase plug
  • Woofer: 8 inch treated paper with rubber surround
  • Input: 4 pin Euroblock

Physical & Dimensions

  • Diameter: 286mm
  • Weight: 3.4kg
