DTDIU Standard Install Digital Controller for P+ / L / ID Series

« return to previous page

NEXO DTDIU Standard Install Digital Controller for P+ / L / ID Series - Main Image

NEXO DTDIU Standard Install Digital Controller for P+ / L / ID Series - Image 1

NEXO DTDIU Standard Install Digital Controller for P+ / L / ID Series - Image 2

NEXO DTDIU Standard Install Digital Controller for P+ / L / ID Series - Image 3

Price:: RRP: £1,087.57 inc VAT
Code:: NEXDTDI
Manufacturer Code:: 01DTD-IU
Brand:: NEXO

Main Features

Speaker controller for ID, P, PS and LS series, providing digital processing from the NXAMP technology (Crossover, EQ, time alignment and speaker protection)
High-end balanced stereo analogue inputs, AES input, USB input
High-end balanced analogue outputs for PS (Stereo) and LS (mono sum)
Automatic amplifier sensing with no setting required from user
Dedicated Install version

Full Description

The DTD-I is a dedicated Installation version, with all connectors (except mini-USB) at the back on the barrier strip. There is no hardware control; everything is set up from a PC/Mac computer connected on the USB port, allowing the settings to be locked and thus preventing any accidental changes.

The DTD delivers advanced speaker control processing taken from the NEXO NXAMP in a compact, rack-mounting device. Providing sophisticated control over crossover, EQ and time-alignment along with speaker protection, the DTD is very easy to use, with automatic amplifier sensing and simple Sub Gain, Main Gain and Crossover Mode control available directly from the front panel (DTD-T touring version). The DTD combines efficient speaker processing with a flexible range of inputs including stereo balanced analogue inputs, an AES input and a USB port enabling direct driverless audio playback from laptops, etc.

DTD uses state-of-the-art audio processing to deliver high- precision EQ and Linear Acoustic Phase algorithms, phase- compatible with all PS and LS cabinets, along with other speakers in the NEXO range. High-end AD and DA converters and 64-bit/96kHz processing ensure an analogue in-to-analogue-out dynamic range greater than 112dB, with distortion kept to under 0.001%.

Features

Product Features

Speaker controller for ID, P, PS and LS series, providing digital processing from the NXAMP technology (Crossover, EQ, time alignment and speaker protection)
High-end balanced stereo analogue inputs, AES input, USB input
High-end balanced analogue outputs for PS (Stereo) and LS (mono sum)
Automatic amplifier sensing with no setting required from user
Dedicated Install version

Technical Specs

Product Specifications

General

Sampling Frequency and Resolution: 48/96 KHz, 64 bits internal processing precision
Signal Delay: Less than 1 ms (analogue into out) on flat setup, compatible with NXAMP latency
Frequency Response: 20 Hz to 20 KHz, +/-0.5 dB (mains out) 20 Hz to 2 KHz +/-0.5 dB (sub out)
Total Harmonic Distortion: Less than 0.001% (mains out) less than 0.02% (sub out)
Dynamic Range: 112 dB (unweighted, mains out) 107 dB (unweighted, sub out)
Crosstalk / Channel Separation: -100 dB (1KHz)
Indicators: Input signal/peak (green/red), amp in signal (green), speaker protect (yellow)
Display: White backlight graphical OLED display 96 x 16 pixels
Switch and Rotary Knobs: 3 position switch + 2 x rotary knobs
Power Supply Voltage: 90 V - 240 V 50/60 Hz
Power Consumption: 20 W max
Heat Dissipation (per hour): 20 Kcal max
Operating Temperature Range: 0°C - 40 °C
Storage Temperature Range: -20 °C - 60 °C

Analog Input Characteristics

Number of channels: 2 electronically balanced analog inputs
Connectors: 2 x terminal block (3-pin / 2.54 mm pitch)
Sampling frequency and resolution: 96 KHz / 24 bits
Max. input level / Input impedance: +22 dBU / 20 KOhms

Amplifier Sensing Inputs

Number of channels: 4 floating electronically balanced high voltage analog inputs
Connectors: 1 x terminal block (8-pin / 5.08 mm pitch)
Sampling frequency and resolution: 48/96 KHz, 24 bits
Max. input level / Input impedance: +50 dBU (8000 Watts / 8 Ohms) / 364 KOhms

AES Input Characteristics

Number of channels: 1 AES/EBU stereo digital input
Connectors: 1 x terminal block (3-pin / 2.54 mm pitch)
Sampling frequency and resolution: 44.1 to 96 KHz / 16, 20 or 24 bits

USB Input Characteristics

Type: 2 channels of USB audio
Connector: Female mini USB connector type B
Sampling frequency and resolution: 48 KHz / 16 bits
Remote Control Connector (DTD-I-U): Mini USB
Remote Control Connector (DTD-I-N): Mini USB + RJ45
