EVE E-50Z LED Ellipsoidal Spot Fixture Inc Gobo Holder

« return to previous page
EVE E-50Z LED Ellipsoidal Spot Fixture Inc Gobo Holder - stage lighting
EVE E-50Z LED Ellipsoidal Spot Fixture Inc Gobo Holder - stage lighting
EVE E-50Z LED Ellipsoidal Spot Fixture Inc Gobo Holder - stage lighting
Front of EVE E-50Z LED Ellipsoidal Spot Fixture Inc Gobo Holder - stage lighting
Back of EVE E-50Z LED Ellipsoidal Spot Fixture Inc Gobo Holder - stage lighting
Price:
RRP: £624.00 inc VAT
Code:
CHAEE50Z
Manufacturer Code:
EVEE50Z
Brand:
CHAUVET DJ

Quantity required:

Main Features

  • LED Ellipsoidal shines a hard-edged, warm white spot in any direction
  • Easily highlight areas by altering the projected beam with framing shutters
  • Flexibility to project from any distance using the manual zoom
  • D-Fi USB compatibility for wireless Master/Slave or DMX control
  • powerCON-compatible power input/output connections for power linking
  • Flicker-free operation suitable for on-camera use
Share:

Chauvet DJ EVE E-50Z

The Chauvet DJ EVE E-50Z is an LED ellipsoidal that shines a hard-edged, warm white spot and features D-Fi™ USB compatibility for wireless Master/Slave or DMX control.  Manual zoom gives you the flexibility to project from any distance and its framing shutters let you easily alter and control the projected beam.

EVE E-50Z includes holders for glass and steel gobos as well as a gel frame. You can operate EVE E-50Z in standalone mode eliminating the need for DMX control and you can save time running extension cords by power linking multiple units in your stage lighting set up.

Live stock levels for a trade accounts. Shipping cut-off at 4pm.



Product Features

  • LED Ellipsoidal shines a hard-edged, warm white spot in any direction
  • Easily highlight areas by altering the projected beam with framing shutters
  • Flexibility to project from any distance using the manual zoom
  • D-Fi USB compatibility for wireless Master/Slave or DMX control
  • powerCON®-compatible power input/output connections for power linking
  • Flicker-free operation suitable for on-camera use
  • Includes holders for glass and steel gobos and a gel frame
  • Save time running extension cords by power linking multiple units
  • Eliminate the need for DMX control with standalone operation
  • Available in black or white

Product Specifications

General

  • DMX Channels:  1 or 3
  • DMX Connectors:  3-pin XLR
  • Light Source:  1 LED (warm white) 50 W, (1.3 A), 50,000 hours life expectancy
  • Strobe Rate:  0 to 29 Hz
  • PWM Frequency:  1.2 kHz
  • Illuminance
    • (20°):  7,910 lux @ 2 m
    • (39°):  2,710 lux @ 2 m
  • Power Linking:  16 units @ 120 V; 26 units @ 230 V
  • Input Voltage:  100 to 240 VAC, 50/60 Hz (auto-ranging)
  • Power and Current
    • 59 W, 0.5 A @ 120 V, 60 Hz
    • 63 W, 0.3 A @ 230 V, 50 Hz
  • Gobo Size:  D (53.3 mm outside, 43 mm image, 2mm max thickness)
  • Zoom Angle:  (manual):  20° to 39

Physical & Dimensions

  • Weight:  4.2 kg
  • Size:  480 x 157 x 381 mm
  • Approvals:  CE
  • Colour Temperature:  3500 K
  • Gel Frame Size:  5.5 in
  • Optional Controllers:  D-Fi USB

What’s in the Box?

  • EVE E-50Z
  • Steel and glass gobo holders
  • Gel frame
  • Power cord
  • Hanging bracket with mounting hardware
