ELX200-12S 12" Passive Subwoofer 800W Black

« return to previous page
Clearance
Electro-Voice ELX200-12S 12 Passive Subwoofer 800W Black - Main Image
Electro-Voice ELX200-12S 12 Passive Subwoofer 800W Black - Image 1
Electro-Voice ELX200-12S 12 Passive Subwoofer 800W Black - Image 2
Electro-Voice ELX200-12S 12 Passive Subwoofer 800W Black - Image 3
Electro-Voice ELX200-12S 12 Passive Subwoofer 800W Black - Image 4
Price:
RRP: £744.48 inc VAT
Code:
ELEELX20012S
Manufacturer Code:
F.01U.351.460
Brand:
Electro-Voice

Quantity required:

Main Features

  • 1600 W (peak), 129 dB peak SPL utilising high sensitivity transducer
  • High-output EVS-12L woofer designed to exacting specifications for superior durability
  • System reliability verified with over 500 hours of endurance & abuse testing
  • Ideal for portable and installed applications
  • Lightweight, compact 15 mm wood enclosure with internal bracing
  • Integrated M20 threaded pole mount plate and two-handle design for easy lifting
Share:

ELX200-12S 12" Passive Subwoofer 800W - Black

The ELX series is designed to deliver an unprecedented combination of sound quality, portability and durability at its price point. All-new custom components—tested to levels far exceeding the industry norm—make ELX200 a robust workhorse capable of handling real-world abuse and professional applications beyond the capability of competitors’ products in its category.

Every aspect of ELX200 is designed for ideal results as part of the whole - the acoustical, electrical and mechanical components all work together seamlessly. The subwoofers pack powerful low-frequency output into a surprisingly compact footprint, and feature tuned 15 mm thick wood enclosures with a premium top-coat finish. The proprietary features that have made the other members of the EV portable speaker family a go-to for best-in-class performance are also present.

EV's industry-leading quality and testing procedures yield efficient transducer design and meaningful specs, resulting in components that deliver accurate, linear response at the system’s highest output levels. Translation: loud and clear all the way up to the limit. Unified in one of the strongest full-range composite enclosures ever built by EV. The ELX200 is established as the new benchmark for toughness - both acoustically and physically; maximum efficiency with maximum toughness.

Product Features

  • 1600 W (peak), 129 dB peak SPL utilising high sensitivity transducer designed and engineered by EV for maximum punch
  • High-output EVS-12L woofer designed to exacting specifications for superior durability and exceptional low-frequency reproduction
  • System reliability verified with over 500 hours of abuse testing and endurance testing
  • Ideal for portable and installed applications
  • Lightweight, compact 15 mm wood enclosure with internal bracing with durable polyurea top-coat finish
  • Professional-grade hardware: integrated M20 threaded pole mount plate and two-handle design for easy lifting
  • Finish: Black

Product Specifications

General

  • Colour: Black
  • Axial Sensitivity (SPL, 1 W @ 1 m): 93dB
  • Connector Type: Dual NL4
  • Enclosure Material: 15 mm plywood with durable polyurea top-coat finish
  • Family: ELX200
  • Frequency Range (-10 dB): 33 Hz - 300 Hz
  • Frequency Response (-3 dB): 42 Hz - 220Hz
  • Grille: 18 AWG steel with powdercoat
  • LF Transducer: EVS-12L 300 mm (12 in)
  • Max. SPL/1m (calc): 129dB
  • Minimum Impedance: 6.9Ω
  • Nominal Impedance: 8 Ω
  • Power Handling (Continuous / Peak): 400 W/1600W
  • Power Rating: 1600W
  • Recommended High-Pass Frequency: 42Hz
  • Speaker Type: Subwoofer

Physical & Dimensions

  • Height: 397mm
  • Width: 445mm
  • Depth: 457mm
  • Woofer Size: 12inch
  • Weight: 20.2kg
