STRIKE V LED Hybrid Strobe / Wash with 180° Tilt RGBW IP65

« return to previous page
CHAUVET Professional STRIKE V LED Hybrid Strobe / Wash with 180° Tilt RGBW IP65 - Main Image
CHAUVET Professional STRIKE V LED Hybrid Strobe / Wash with 180° Tilt RGBW IP65 - Image 1
CHAUVET Professional STRIKE V LED Hybrid Strobe / Wash with 180° Tilt RGBW IP65 - Image 2
CHAUVET Professional STRIKE V LED Hybrid Strobe / Wash with 180° Tilt RGBW IP65 - Image 3
CHAUVET Professional STRIKE V LED Hybrid Strobe / Wash with 180° Tilt RGBW IP65 - Image 4
CHAUVET Professional STRIKE V LED Hybrid Strobe / Wash with 180° Tilt RGBW IP65 - Image 5
Price:
RRP: £3,840.00 inc VAT
Code:
CHASTRIKEV
Manufacturer Code:
STRIKEV
Brand:
CHAUVET Professional

Quantity required:

Main Features

  • Fully featured, high-power, 180° tilting hybrid strobe/wash with IP65 rating for all-weather use
  • 48 individually controllable pixels across two layers of LEDs
  • Variable electronic frost for added eye candy effects
  • Included magnetically attachable stealth filter for hiding the LEDs when not in use
  • 16-bit dimming of master dimmer for smooth control of fades
  • RDM control over DMX for fixture reporting
Share:

STRIKE V LED Hybrid Strobe / Wash with 180° Tilt RGBW IP65

Our newest STRIKE design introduces dynamic dual-layer pixel effects with a punchy flair that brings totally new and unique looks to our tour-proven STRIKE family of IP65-rated strobes and blinders. STRIKE V features dual LED diodes, under a variable electronic frost plate that can change beam angles instantly at the press of a button, and together offer fresh new multicolor creative possibilities. Advanced eye-candy effects, vibrant colour washes, and stunning strobe capabilities from a motorized 180° tilting strobe/wash hybrid designed for powerful performance in the most demanding applications and conditions.

Product Features

  • Fully featured, high-power, 180° tilting hybrid strobe/wash with IP65 rating for all-weather use
  • 48 individually controllable pixels across two layers of LEDs
  • Variable electronic frost for added eye candy effects
  • Included magnetically attachable stealth filter for hiding the LEDs when not in use
  • Multiple mounting locations and repositionable yoke with ¼ turn adaptors for creative and convenient rigging options in vertical and horizontal orientations
  • RDM control over DMX for fixture reporting
  • 16-bit dimming of master dimmer for smooth control of fades
  • Easy-to-use OLED display
  • Rugged design for years of rough use in the most extreme conditions.
  • Adjustable Pulse Width Modulation (PWM) for added flexibility
  • USB port for fixture software updates
  • Built-in alignment pins to insure perfectly straight linear arrays
  • Failsafe Ethernet connectivity allows for data to pass even if fixture power is lost

Product Specifications

Optical

  • Light Source:  24 LEDs top plate (quad-color RGBW), 6W, 50,000 hours life expectancy
  • Light Source:  24 LEDs bottom plate (quad-color RGBW), 50W, 50,000 hours life expectancy
  • Beam Angle (Combine):  9.9°
  • Beam Angle (Dot):  105.7°
  • Beam Angle (Cell):  9.9°
  • Beam Angle (w/E-Frost Combine):  50.3°
  • Beam Angle (w/E-Frost Dot):  103.1°
  • Beam Angle (w/E-Frost Cell):  46.8°
  • Field Angle (Combine):  17.6°
  • Field Angle (Top Plate):  153.1°
  • Field Angle (Cell):  17.5°
  • Field Angle (w/E-Frost Combine):  125°
  • Field Angle (w/E-Frost Dot):  155.6°
  • Field Angle (w/E-Frost Cell):  117.2°
  • Lumens (Combine):  19,589
  • Lumens (Dot):  1,912
  • Lumens (Cell):  17,127
  • Lumens (w/E-Frost Combine):  13,406
  • Lumens (w/E-Frost Dot):  1,633
  • Lumens (w/E-Frost Cell):  15,769
  • Illuminance (Combine):  16,779 lux @ 5 m
  • Illuminance (Dot):  29 lux @ 5 m
  • Illuminance (Cell):  16,789 lux @ 5 m
  • Illuminance (w/E-Frost Combine):  539 lux @ 5 m
  • Illuminance (w/E-Frost Dot):  26 lux @ 5 m
  • Illuminance (w/E-Frost Cell):  536 lux @ 5 m
  • Selectable PWM:  1000Hz, 2000 Hz, 4000 Hz, 6000 Hz, 25000 Hz, 64,000 Hz

Dynamic Effects

  • Tilt:  180°
  • Tilt Ranges:  0° to 180°
  • Dimmer:  Electronic
  • Shutter/Strobe:  Electronic
  • Strobe Rate:  0 to 30 Hz
  • Standalone Colour Mixing:  Yes
  • Dim Modes:  4
  • Built-in Automated Programs:  Yes

Certifications / Qualifications

  • CE, MET, ROHS, FCC
  • IP Rating:  IP65, temporary outdoor/wet use, with pressure equalizing M12 GORE valve
  • Temperature (Ambient):  14 °F to 113 °F (-10 °C to 45 °C)
  • Temperature (Ambient):  14 °F to 113 °F (-10 °C to 45 °C)

Construction / Physical

  • Dimensions:  16 x 7.3 x 12.2 in (407 x 187.4 x 310 mm)
  • Weight:  36 lb (16.3 kg)
  • Exterior Colour:  Black
  • Housing Material:  AZ91D Magnesium diecast

What's in the Box?

  • STRIKE V
  • Seetronic Powerkon IP65 power cord
  • Omega bracket
  • Stealth filter
