Vocia LSI-16 Emergency Line Safety Interface for Vocia

Biamp Vocia LSI-16 Emergency Line Safety Interface for Vocia - Main Image

Biamp Vocia LSI-16 Emergency Line Safety Interface for Vocia - Image 1

Biamp Vocia LSI-16 Emergency Line Safety Interface for Vocia - Image 2

Price:: RRP: £2,421.60 inc VAT
Code:: BIAVLSI16
Manufacturer Code:: 911.0245.900
Brand:: Biamp

Main Features

Parallel I/O ports for direct interface with fire alarm and emergency equipment
8 monitored I/O and 8 control inputs
Redundant network connection and power supply options
Power and data over a single Ethernet cable
Local storage of configuration data
Rotary switches for unit identification

Vocia LSI-16

The Vocia® Life Safety Interface 16 (LSI-16) is a networked device that serves as an interface between a Vocia system and emergency or fire alarm systems. The LSI-16 may accept up to three sources of power: main power is from an external, standards compliant, battery backed 24V DC source but the LSI-16 can also utilise Power over Ethernet (PoE) delivered via either of its two network ports. The device is equipped with parallel I/O ports for direct interface to fire and emergency control equipment. The LSI-16 uses Ethernet-based control protocols to function within a Vocia system.

Product Features

Parallel I/O ports for direct interface with fire alarm and emergency equipment
8 monitored I/O and 8 control inputs
Redundant network connection and power supply options
Power and data over a single Ethernet cable
Local storage of configuration data
Rotary switches for unit identification
Accepts the Interface Module 16 (IM-16) for 16 additional general purpose inputs
Status LEDs
Rack mountable (1RU)
Up to 4 discrete emergency inputs
Up to 500 virtual inputs via RS-232 port or Ethernet
RoHS compliant
Covered by Biamp Systems’ five-year warranty

Product Specifications

General

Network Connection: RJ-45 with shielded Ethernet (CAT5, CAT5e, CAT6 or CAT7
System Fault Relay:
- Type:
  - Single Form C voltage-free
  - SPST change-over contact
- Load: Resistive
- Max Operating Voltage: 125VAC, 60VDC
- Max Operating Current: 600mA AC, 1A DC
- Max switching capacity: 37.5VA, 30W
- Min permissible load: 10μA @ 10mVDC
Control Inputs:
- Number: Eight
- Type: Opto Isolator LED
- Current:
  - Min: 1mA
  - Max: 6mA
- Maximum Terminal Voltage: 24V
- Isolation: 3kV
Monitored I/O:
- Number: Eight
- Type: FET switch, open drain (low side driver)
Max Continuous Current: 0.35A
- Current Limit: 0.8A
- Maximum External Supply: 35V
- VMon Input Shutdown: 35V
RS232 Port:
- Type: DTE
- Baud Rate: 57600
Power:
- Main: 24V DC 15W
- PoE: 802.3af Class 3
Environment:
- Ambient Operating Temperature Range: 23-104° F (-5 – 40° C)
- Humidity: 0 – 95% non-condensing
- Altitude: 0-10,000 Feet (0-3000 Meters) MSL
