BS5EN 5" Coaxial Pendant Speaker 20W EN54-24 100V IP65 White

« return to previous page
RCF BS5EN 5 Coaxial Pendant Speaker 20W EN54-24 100V IP65 White - Main Image
RCF BS5EN 5 Coaxial Pendant Speaker 20W EN54-24 100V IP65 White - Image 1
RCF BS5EN 5 Coaxial Pendant Speaker 20W EN54-24 100V IP65 White - Image 2
RCF BS5EN 5 Coaxial Pendant Speaker 20W EN54-24 100V IP65 White - Image 3
RCF BS5EN 5 Coaxial Pendant Speaker 20W EN54-24 100V IP65 White - Image 4
Price:
RRP: £172.80 inc VAT
Code:
RCFBS5EN
Manufacturer Code:
13133078
Brand:
RCF

Quantity required:

Main Features

  • Suspended Sound Projector
  • 5" coaxial woofer with 0.75" dome tweeter.
  • Power selectable (100 V): 20 W – 10 W – 5 W – 2.5 W.
  • Colour white RAL 9016.
  • Protection grade IP65.
  • 5 m cable included.
Share:

BS 5EN 5" Suspended Sound Projector 10W EN54-24 - IP65

BS 5EN is a pendant speaker suitable for all those installations where high intelligibility for alarm messages broadcasting and great sound reproduction quality are required. Thanks to its IP65 protection grade, it can be installed both indoor and outdoor. Moreover, a modern and endearing design makes it the perfect product for environments where projectors are intended also as architectural elements and contribute to improve global aesthetics.

Product Features

  • Suspended Sound Projector
  • 5" coaxial woofer with 0.75" dome tweeter.
  • Power selectable (100 V): 20 W – 10 W – 5 W – 2.5 W.
  • 88 dB sensitivity.
  • Colour white RAL 9016.
  • Flameproof ABS body, steel grille.
  • In/out ceramic terminal block.
  • Thermal fuse protection.
  • Protection grade IP65.
  • 5 m cable included.

Product Specifications

Acoustical specifications

  • Frequency Response (-10dB): 80 Hz ÷ 20000 Hz
  • Max SPL @ 1m: 101 dB
  • Max SPL @ 4m: 89 dB
  • Coverage angle: 170°
  • System Sensitivity: 88 dB
  • System Sensitivity 1W @ 4m: 76 dB

Power section

  • Power Handling: 20 W RMS
  • Peak Power Handling: 80 W PEAK
  • Recommended Amplifier: 40 W
  • Protections: Thermal fuse

Transducers

  • Dome Tweeter: 0.75''
  • Woofer: Coaxial 5.0''

Input/Output section

  • Input connectors: Ceramic screw terminals
  • Output connectors: Ceramic screw terminals
  • Constant Voltage Transformer: 100 V
  • Power selection 1: 20 W - 500 ohm
  • Power selection 2: 10 W - 1000 ohm
  • Power selection 3: 5 W - 2000 ohm
  • Power selection 4: 2.5 W - 4000 ohm

Standard compliance

  • IP protection grade: IP 65
  • EN54-24 certified: Yes
  • CE marking: Yes
  • CPR number: 0068-CPR-058/2014

Physical specifications

  • Cabinet/Case Material: ABS
  • Hardware: Wall mount metal plate and 5m cable
  • Grille: Steel
  • Colour: White - RAL 9016

Size

  • Height: 261 mm / 10.28 inches
  • Width: 176 mm / 6.93 inches
  • Depth: 183 mm / 7.2 inches
  • Weight: 2.79 kg / 6.15 lbs

Shipping information

  • Package Height: 230 mm / 9.06 inches
  • Package Width: 350 mm / 13.78 inches
  • Package Depth: 230 mm / 9.06 inches
  • Package Weight: 3.71 kg / 8.18 lbs
