DEC6104 Expander Board for FORUM 6000 add up to 180 DMS6410

« return to previous page
RCF DEC6104 Expander Board for FORUM 6000 add up to 180 DMS6410 - Main Image
Price:
RRP: £874.80 inc VAT
Code:
RCFDEC6104
Manufacturer Code:
17180034
Brand:
RCF

Quantity required:

Main Features

  • DEC6104 Expander Board for FORUM 6000
  • Up to 180 DMS 6410 microphone consoles on 6 lines
  • USB port to connect the system to a PC
  • FORUM 6000 control software included
  • RS 485 port
  • Anti-feedback processor, useful to avoid feedbacks due to loudspeakers too close to microphones
Share:

DEC6104 Expander Board for FORUM 6000 add up to 180 DMS6410

The DEC 6104 board is to be installed into the DMU 6100 main unit of the RCF FORUM 6000 conference system. This board adds features: Up to 180 DMS 6410 microphone consoles, USB port to connect the system to a PC, RS 485 port (alternative to the USB port), Anti-feedback processor, useful to avoid feedbacks due to loudspeakers too close to microphones, loudspeaker high volume and many open microphones at the same time. Included is the software FSW 6000 that manage and control the conference system.

Product Features

  • DEC6104 Expander Board for FORUM 6000
  • Up to 180 DMS 6410 microphone consoles on 6 lines (4 line outputs are on the DEC 6104 board)
  • The further 120 consoles shall be powered by the DPS 6202 power supply unit
  • USB port to connect the system to a PC
  • FORUM 6000 control software included
  • RS 485 port (alternative to the USB port) for long distance control (up to 1.2 km) of the system through the PC software
  • Anti-feedback processor, useful to avoid feedbacks due to loudspeakers too close to microphones, loudspeaker high volume and many open microphones at the same time.

Product Specifications

General

  • Controls
    • CONFIGURATION: PC Software
  • Processing
    • DSP: Yes
  • Input section
    • BALANCED: 4
    • LINE CONNECTORS: RCA
    • LINE INPUTS: 1
    • MONO: 5
    • PAGING CONNECTORS: RJ45
    • PAGING INPUTS: 4
    • TOTAL NUMBER OF INPUTS: 5
    • UNBALANCED: 1
  • Output section
    • SIGNAL OUTPUT CONNECTORS: RCA
    • SIGNAL OUTPUT NUMBER: 1
  • Power requirement
    • DC POWER: Yes
    • DC POWER VALUE: 48 V

Physical & Dimensions

  • Weight: 0.82kg
