LSR705i 5" 2-Way Powered Master Reference Monitor Speaker

« return to previous page
JBL LSR705i 5 2-Way Powered Master Reference Monitor Speaker - Main Image
JBL LSR705i 5 2-Way Powered Master Reference Monitor Speaker - Image 1
JBL LSR705i 5 2-Way Powered Master Reference Monitor Speaker - Image 2
Price:
RRP: £1,368.00 inc VAT
Code:
JBLLSR705I
Manufacturer Code:
JBL1639
Brand:
JBL

Quantity required:

Main Features

  • Master Reference Monitor
  • Next Generation Driver Technology
  • Compact, Install Friendly Enclosures
  • A seamless crossover and uncoloured response in the critical dialogue range.
  • Neutral off-axis response for greater accuracy and room-toroom consistency
  • Detailed imaging and a coherent transition between screen channels, surrounds and overhead speakers.
Share:

705i 5" Master Reference Monitor

The first in JBL’s 7 Series line, the 705i and 708i models answer the call for next generation multi-channel monitoring in post rooms, broadcast facilities and trucks. Leveraging patented technologies developed for our flagship M2 Master Reference Monitor, 7 Series Studio Monitors deliver detailed imaging, extended frequency response and remarkable output from compact enclosures. Centrally amplified and tuned, and easily installed, 705i and 708i Studio Monitors are the heart of an elegant, scalable system for broadcast and post facilities working in immersive audio formats.

Product Features

  • Next Generation Systems for Post and Broadcast Production in Control Rooms and Trucks
  • Next Generation Driver Technology
  • Patent Pending Image Control Waveguide
  • Compact, Install Friendly Enclosures
  • A seamless crossover and uncoloured response in the critical dialogue range.
  • Neutral off-axis response for greater accuracy and room-toroom consistency
  • Detailed imaging and a coherent transition between screen channels, surrounds and overhead speakers.

Product Specifications

General

  • Frequency Response (±3 dB):  48 Hz – 23 kHz
  • Frequency Range:  39Hz – 36 kHz
  • Maximum Continuous SPL:  (80 Hz - 20 kHz) >101 dB SPL / 1m
  • Maximum Peak SPL:  (80 Hz - 20 kHz) >107 dB SPL / 1m
  • HF Driver:  2409H
  • LF Driver:  725G - 5in (127mm)
  • Dividing Network Transition Frequency:  1.9 kHz
  • Input Connectors:  Phoenix Terminals accept 12 gauge speaker wire

Physical

  • Dimensions (HxWxD):  10.5 x 5.875 x 8.125 in (267 x 149 x 206 mm)
  • Net Weight (each):  9.0 lb (4.08 kg)
  • Enclosure:  Birch plywood reinforced for mounting
  • Mounting:  Top, bottom and rear mounting points. 2-hole mounting pattern
