PC-2852 Round Surface Ceiling Speaker 15W/100V White

« return to previous page
TOA PC-2852 Round Surface Ceiling Speaker 15W/100V White - Main Image
Price:
RRP: £69.00 inc VAT
Code:
TOAPC2852
Manufacturer Code:
PC-2852
Brand:
TOA

Quantity required:

Main Features

  • 20 cm speaker
  • Rated input 15 W
  • Very high sound pressure level
  • For paging and BGM
  • Easy installation with spring catches
  • Push-in terminals
Share:

PC2852 Round Surface Ceiling Speaker 15W/100V - White

Integrated with a speaker unit and panel, the PC-2852 Ceiling Mount Speaker is of all metallic construction and ideal for use in a voice alarm system. It features a spring clamp mechanism for easy speaker mounting to the ceiling. The input impedance can be easily changed by changing the tap position of the transformer. The push-in type input terminal block makes cable connections easy and allows bridge wiring.

Product Features

  • 20 cm speaker
  • Rated input 15 W
  • Very high sound pressure level
  • For paging and BGM
  • Easy installation with spring catches
  • Push-in terminals
  • Bridge wiring

Applications

  • Multipurpose halls
  • Shopping centres
  • Hotels
  • Educational facilities
  • Retail stores
  • Hospitals / Health Care
  • Exhibition centres

Product Specifications

General

  • Frequency response:  45 Hz - 20 kHz
  • Sensitivity (1 W, 1 m):  96 dB
  • Speaker component:  20 cm coaxial cone-type
  • Rated input (High Impedance):  15 W, 7,5 W
  • Tappings:  15 / 10 / 5 / 3 W (100 V), 15 / 7.5 / 5 / 2.5 / 1.5 W (70 V)

Physical

  • Mounting hole:  250 mm
  • Dimensions (ø x D):  280 x 93 mm
  • Finish:  Steel plate, traffic white (RAL 9016 or equivalent)
