RTA-M RTA Microphone for DriveRack PA/PX/AFS224/Zone Pro

« return to previous page
dbx RTA-M RTA Microphone for DriveRack PA/PX/AFS224/Zone Pro - Main Image
Price:
RRP: £204.00 inc VAT
Code:
DBXRTAM
Manufacturer Code:
DBX0100
Brand:
dbx

Quantity required:

Main Features

  • Polar Pattern: omni-directional
  • Element: back electret-Condenser
  • Frequency Response: 20 Hz - 20 kHz
  • Impedance: 250 30% (at 1,000Hz)
  • Sensitivity: -63 dB +-3 dB ( 0 dB=1V/ microbar 1,000 Hz indicated by open circuit )
  • Operating Voltage: phantom power 9V-52VDC
Share:

RTA-M RTA Reference / Measurement Microphone for DriveRack

The optional RTA-M real time audio analyzing mic is the perfect accessory tool for the DriveRack PA, DriveRack PA+ and 260. Used in conjunction with the System Setup Wizard and Auto EQ Wizard the RTA-M is ideal for optimizing the sound quality of even the most difficult of acoustic environments.

The RTA-M is an omni-directional, flat frequency measurement microphone specially designed for the Driverack series to pick up all frequencies from 20 Hz to 20 kHz , ensuring accurate "pinking"/real-time analysis of your audio. It runs on phantom power (supplied by the Driverack units) and comes with a clip and case.

Product Features

  • Polar Pattern : omni-directional
  • Element : back electret-Condenser
  • Frequency Response : 20 Hz - 20 kHz
  • Impedance : 250 30% (at 1,000Hz)
  • Sensitivity : -63 dB +-3 dB ( 0 dB=1V/ microbar 1,000 Hz indicated by open circuit )
  • Operating Voltage : phantom power 9V-52VDC
