TERRA-EX2 IP Audio Decoder 1xStereo or 2xMono Outputs & RS232

« return to previous page
Terracom TERRA-EX2 IP Audio Decoder 1xStereo or 2xMono Outputs & RS232 - Main Image
Price:
RRP: £549.76 inc VAT
Code:
TERRAEX2
Manufacturer Code:
TERRA-EX2
Brand:
Terracom

Quantity required:

Main Features

  • TERRA-EX2: 1 x stereo or 2 x mono outputs, 3 x contact inputs, 1 x contact output, 1 x RS232
  • 3 contact inputs and 1 contact output
  • 2 balanced line outputs (1 stereo or 2 mono)
  • 1 stereo line output (3.5 mm mini-jack) for headphone
  • Audio output: maximum level +5 dB, bandwidth 20 Hz ˜ 20 kHz
  • Single CAT5/6 cable connectivity for audio and control
Share:

TERRA-EX2 IP Audio Decoder 1xStereo or 2xMono Outputs & RS232

An IP, POE audio decoder which can be used for voice, paging, intercom, music streaming, audio routing, pre-recorded and scheduled announcements, VoIP communication or as a SIP device. Utilise this module by receiving digitised audio from a network and provide an analogue output with I/O or optional RS232 control.

Integrated shoutcast/icecast decoding, scheduler and internal storage are just some of the features of this IP decoder. Optional USB interface is available.

To configure, control and monitor the TERRA-IEX in real-time, this is simply achieved through your favourite web browser making the management of even the most complex environments a simple and straight forward process.

TERRA-EX2: 1 x stereo or 2 x mono outputs, 3 x contact inputs, 1 x contact output, 1 x RS232

Product Features

  • TERRA-EX2: 1 x stereo or 2 x mono outputs, 3 x contact inputs, 1 x contact output, 1 x RS232
  • 3 contact inputs and 1 contact output
  • 2 balanced line outputs (1 stereo or 2 mono)
  • 1 stereo line output (3.5 mm mini-jack) for headphone
  • Audio output: maximum level +5 dB, bandwidth 20 Hz ˜ 20 kHz
  • Single CAT5/6 cable connectivity for audio and control
  • PoE or 24 VDC power supply (if PoE is not available)
  • Support G.711, G.722, G.726, G.727, G.729, MP3 audio codec and AAC+ (decoding only)

Product Specifications

  • Audio output: maximum level +5 dB, bandwidth 20 Hz ˜ 20 kHz
  • 3 contact inputs and 1 contact output
  • 2 balanced line outputs (1 stereo or 2 mono)
  • 1 stereo line output (3.5 mm mini-jack) for headphone
  • PoE or 24 VDC power supply (if PoE is not available)
  • Power consumption: 2W
  • Weight: 0.95 lb (433g)
  • Dimensions (DxHxW): 4" x 1-1/4" x 4-3/10" (104 mm x 32 mm x 109 mm)
