TX1181 Tour X 1x18" Subwoofer with Integral Xover 500W

« return to previous page
Electro-Voice TX1181 Tour X 1x18 Subwoofer with Integral  Xover 500W - Main Image
Electro-Voice TX1181 Tour X 1x18 Subwoofer with Integral  Xover 500W - Image 1
Electro-Voice TX1181 Tour X 1x18 Subwoofer with Integral  Xover 500W - Image 2
Price:
RRP: £1,081.80 inc VAT
Code:
ELETX1181
Manufacturer Code:
F.01U.302.275
Brand:
Electro-Voice

Quantity required:

Main Features

  • High-power LF supplement to TX1122 and TX1152
  • High-excursion EVS-18S woofer
  • 6 dB/octave low-pass filter for parallel connection without added amp
  • Top-side socket for speaker pole
  • Mount points (6) for optional wheel kit
  • Braced plywood/MDF enclosure
Share:

TX1181 Tour X 1x18" Subwoofer with Integral  Xover 500W

Tour X brings the engineering excellence and aesthetic design of EV's world-class tour systems to an innovative and exciting series of portable loudspeakers. Combining bold design and breakthrough performance, the Tour X series is optimized for applications, such as club sound, pro music and concert sound. The line's full-range loudspeakers and monitors utilize either 1.25" DH3/2010A or 2" ND2 compression drivers, protected by an advanced fourth-order crossover.

Product Features

  • High-power LF supplement to TX1122 and TX1152
  • High-excursion EVS-18S woofer
  • 6 dB/octave low-pass filter for parallel connection without added amp
  • 100 dB sensitivity, 132 dB maximum SPL
  • Power handling: 500 W continuous, 2000 W peak
  • Top-side socket for speaker pole
  • Six mount points for optional wheel kit
  • Braced plywood/MDF enclosure
  • Black EVCoat finish

Product Specifications

General

  • Enclosure Material: Plywood and MDF with EVCOAT
  • Family: Tour X
  • Flying: No
  • Frequency Response (-10 dB): 45 - 700 Hz
  • Frequency Response (-3 dB): 50 - 160 Hz
  • Input Connections: Parallel Neutrik® NL4
  • Internal Crossover: Low-pass filter
  • LF Transducer: 18-inch EVS18S
  • Max. SPL/1m (calc): 132 dB
  • Minimum Impedance: 7.5Ω
  • Nominal Impedance (Passive): 8Ω
  • Power Rating: 2000W
  • Powered or Passive: Passive
  • Recommended High-Pass Frequency: 30Hz
  • Sensitivity 1 W/1 m: 100dB
  • Speaker Type: Subwoofer
  • System Power Handling (Continuous/Program/Peak): 500//2000 Watts

Physical & Dimensions

  • Height: 769mm
  • Width: 508mm
  • Depth: 591mm
  • Weight: 33.8kg
