Main Features
Active 8-channel 0 dB transmitter combiner with highly constant RF output power over the entire frequency range
Significant improvement of RF performance for multi-channel systems
Broadband RF design to cover the UHF frequency range from 500-870 MHz
Maximum input power of 250 mW
LEDs on the front show whether a signal is present at the RF input
Compatible with SR 3054, SR 3056, SR 3254, SR 3256, SR 300 and SR 350 transmitters
AC3200MKII Active 8-1 Antenna Combiner for 8xSR2020D
The AC 3200-II is an active 8-channel transmitter combiner for bundling the antenna signals in large wireless monitoring systems. Designed for the 2000 Series rack-mount monitor transmitters, it is ideal for large productions where reliable transmission and long reach are key. The AC 3200-II allows up to eight signals to be transmitted from a single antenna. In multi-channel systems it is an indispensable tool for efficiently reducing intermodulation between transmission channels. Linear power amplifiers handle up to 100 mW per channel without loss, and LEDs for each channel provide the user with a reliable system overview.
Product Features
The AC 3200-II combines up to 8 signals and transmits them via a single antenna
The AC 3200-II combines signals of up to 8 x 100 mW without loss
Significant suppression of intermodulation products between the connected transmitters
Product Specifications
General
Impedance: 50 ohms
Attenuation: 0 dB (+/- 1dB)
Power consumption max.: 90 W
Operating temperature: -10 °C to +45 °C
RF frequency range: 500 – 870 MHz
Power supply: 12 V DC
Antenna connector: BNC
Current consumption max.: 7.5 A
Physical & Dimensions
Dimensions: 17.1 x 1.7 x 9.8 in (436 x 44 x 250 mm)
