Vortex 12A 12" 2-Way Active Portable PA Speaker 350W

« return to previous page
Studiomaster Vortex 12A 12 2-Way Active Portable PA Speaker 350W - Main Image
Studiomaster Vortex 12A 12 2-Way Active Portable PA Speaker 350W - Image 1
Studiomaster Vortex 12A 12 2-Way Active Portable PA Speaker 350W - Image 2
Studiomaster Vortex 12A 12 2-Way Active Portable PA Speaker 350W - Image 3
Price:
RRP: £389.00 inc VAT
Code:
STUVOR12A
Manufacturer Code:
5060255345429
Brand:
Studiomaster

Quantity required:

Main Features

  • 1400W 2-way amplification
  • 125dB SPL
  • Multiple M10 flying points
  • Dual top hat sockets:  Straight (0 degree)  Angled (10 degree)
  • Floor monitor suitable
  • with TWS facility
Share:

Vortex 12A 12" 2-Way Active Portable PA Speaker 350W

A brand new 12″ active moulded speaker cabinets. Featuring high performance 1400W (peak) power amplifiers and a unique coaxial speaker configuration. The Vortex series are designed to perform and exceed your expectations and requirements for lightweight, portable PA cabinets.

The all new VORTEX series feature set is considerable, with Bluetooth input with TWS, built in DSP control, Dual 35mm top hat sockets, triple input channels, multiple M10 flying points, up to 3 carry handles for portability and much more.

Product Features

  • Full face front grille
  • Moulded cabinet
  • 15.5kg
  • Multiple handle positions
  •  top and both sides
  • 1400W 2-way amplification
  • 125dB SPL
  • Multiple M10 flying points
  • Dual top hat sockets:  Straight (0 degree)  Angled (10 degree)
  • Floor monitor suitable
  • with TWS facility
  • 24 BIT DSP
  • 3 Band EQ
  • Multiple operation modes
  • Limiter
  • Time delay
  • 2x mic / line
  • 1x 3.5mm line
  • Bluetooth
  • Selectable between input A and full mix

Product Specifications

  • Cabinet type:  12″ 2-way coaxial active
  • Max SPL:  125dB
  • Amp peak:  1400w
  • Max PGM:  700w
  • Amp RMS:  350w (300+50)
  • Weight (NET):  15.5kg
  • Freq response:  50Hz-20kHz
  • Input sensitivity:  0dBu
  • Coverage(h x v):  80 x 80 degree
  • LF driver:  12″ / 65mm VC
  • HF driver:  34mm VC / 1″ throat
  • Crossover FREQUENCY:  2.2kHz
  • 24bit DSP:  Mode select, 3 band EQ, delay, volume
  • DSP Modes:  Music, live, dj, speech, monitor
  • Connection:  2x XLR/JACK input, 1x 3.5mm, XLR output
  • Connectivity:   bluetooth playback
  • Mounting:    Dual top-hat, 5x M10 flying points
  • Dimensions (W/H/D):  360 / 585 / 310mm
